Fire Alarm Cable
Application areasSuitable for fire alarm signal circuits, smoke detectors, voice communication, audio, control, activation, and notification circuits.

Main Features
Compliant with RoHS & REACH environmental standards,High flame retardancy for enhanced safety,Long service life, resistant to aging,Reliable and durable performance in critical conditions
Structure and Technical Parameters
Conductors oxygen free bare copper,tin-coated copper
Insulators PVC、LSZH Shielding Unshielded, overall shielding
Ripcord fiber ropes Sheaths PVC、LSZH Working Voltage 300V Working Temperature -40℃~+105℃ Environmental Performance RoHS2.0、REACH Certification UL、CPR、CCC Flame Retardants IEC60332-1、IEC60332-3、VW-1、FPL、FPLR、FPLP、FT4、FT6 Other Options cold resistant,water proof ,fire resistant ,UV resistant,oil resistant


Specification List

Resource Download List

(3C×18AWG Armour Power-Limited Fire Cable FT4) Specification

Download‍

(5C×16AWG Armour Power-Limited Fire Cable FT4) Specification

Download‍

Fire alarm cable (fire-resistant cable) 1.5mm² BC 3C LSZH PH30 red

Download‍

Fire Alarm Cable (Fire-Resistant Cable) 1.5mm² BC 3C Shielded LSZH PH30 Red

Download‍

1.5mm² 4C Stranded FPLR Fire Alarm Cable Specification

Download‍

2CX1.5mm² Fire Alarm Wire Specification

Download‍

2CX2.5mm²   FPLR Fire Alarm Wire Specification

Download‍

2CX2.5mm² Fire Alarm Wire Specification

Download‍

3C×14AWG+2C×16AWG Power-Limited Fire Cable FT4) Specification

Download‍

3C×14AWG+2C×16AWG Power-Limited Fire Cable FT4 Specification

Download‍

3C×16AWG Armour Power-Limited Fire Cable FT4 ) Specification

Download‍

3C×16AWG Armour Power-Limited Fire Cable FT4 Specification

Download‍

3C×18AWG Armour Power-Limited Fire Cable FT4 Specification

Download‍

3C×18AWG Armour Power-Limited Fire Cable FT4 Specification

Download‍

5C×18AWG Armour   Power-Limited Fire Cable FT4) Specification

Download‍

5C×18AWG Armour   Power-Limited Fire Cable FT4 Specification

Download‍

5C×18AWG Power-Limited Fire Cable FT4 Specification 2

Download‍

5C×18AWG Power-Limited Fire Cable FT4 Specification

Download‍

12AWG 2C FPLR Shielded Fire Alarm Cable Specification

Download‍

Tianjie Brand Fire Alarm Cable Shielded PVC FPLR Specification

Download‍

Tianjie Brand Fire Alarm Cable Shielded PVC FPLR Specification

Download‍

Fire Alarm Cable   16AWG BC 2C Shielded PVC   Underground Black) Specification

Download‍

Fire Alarm Cable   16AWG BC 2C Shielded PVC   Underground Black) Specification

Download‍

Fire Alarm Cable   18AWG BC 2C Shielded PVC   Underground Black) Specification

Download‍

Fire Alarm Cable   18AWG BC 4C Shielded PVC Underground Black) Specification

Download‍

Fire Alarm Cable   CMP 22AWG 4C Specification

Download‍

Fire Alarm Line   FPLP 12AWG 2C Specification

Download‍

Fire Alarm Line   FPLP 14AWG 2CSpecification

Download‍

Fire Alarm Line   FPLP 16AWG 2C Specification

Download‍

Fire Alarm Line   FPLP 16AWG 4C Specification

Download‍

Fire Alarm Line   FPLP 18AWG 2C Specification

Download‍

Fire Alarm Line   FPLP 18AWG 4C Specification

Download‍

Fire Alarm Line   FPLP 18AWG 6CSpecification

Download‍

Fire Alarm Line   FPLP 18AWG 6C Specification

Download‍

Fire Alarm Line   FPLR 12AWG 2C Specification

Download‍

Fire Alarm Line   FPLR 14AWG 2C Specification

Download‍

Fire Alarm Line   FPLR 16AWG 2C Specification

Download‍

Fire Alarm Line   FPLR 16AWG 4C Specification

Download‍

Fire Alarm Line   FPLR 18AWG 2C Specification

Download‍

Fire Alarm Line   FPLR 18AWG 4C Specification

Download‍

Fire Alarm Line   Shielded FPLP 12AWG 2C Specification

Download‍

Fire Alarm Line   Shielded FPLP 16AWG 2C Specification

Download‍

Fire Alarm Line   Shielded FPLP 16AWG 4C Specification

Download‍

Fire Alarm Line   Shielded FPLR 14AWG 2C Specification

Download‍

Fire Alarm Line   Shielded FPLR 16AWG 2C Specification

Download‍

Fire Alarm Line   Shielded FPLR 16AWG 2C Specification

Download‍

Fire Alarm Cable 1.5mm² BC 2C Shielded PVC CMR Red Specification

Download‍

Fire Alarm Line 2CX1.5² Shielded Specification

Download‍

Fire Alarm Cable 2Cx1.5mm² Shielded Polyester Film Specification

Download‍

Fire Alarm Line 2CX2.5² Shielded Specification

Download‍

Fire Alarm Cable 14AWG BC 2C LSZH FPL Red Specification

Download‍

Fire Alarm Cable 14AWG BC 2C LSZH FPLR Red Specification

Download‍

Fire Alarm Cable 14AWG BC 2C PVC FPLR Red Specification

Download‍

Fire Alarm Cable 16AWG BC 2C LSZH FPL Red Specification

Download‍

Fire Alarm Cable 16AWG BC 2C LSZH FPLR Red Specification

Download‍

Fire Alarm Cable 16AWG BC 2C PVC FPLR Red Specification

Download‍

Fire Alarm Cable 16AWG BC 2C Shielded PVC FPLR Red Specification

Download‍

Fire Alarm Cable 16AWG BC 2C Shielded PVC FPLR Red Specification

Download‍

Fire Alarm Cable 18AWG BC 2C LSZH FPLR Red Specification

Download‍

Fire Alarm Cable 18AWG BC 2C PVC FPLR Red Specification

Download‍

Fire Alarm Cable 18AWG BC 4C LSZH FPL Red Specification

Download‍

Fire Alarm Cable 18AWG BC 4C LSZH FPLR Red Specification

Download‍

Fire Alarm Cable 18AWG BC 4C PVC FPLR Red Specification

Download‍

Fire Alarm Cable 22AWG BC 4C LSZH FPLR Red Specification

Download‍

Fire Alarm Cable 22AWG BC 4C LSZH FPL Red Specification

Download‍

Fire Alarm Cable 22AWG BC 4C PVC FPLR Red Specification

Download‍

Fire Alarm Line Shielded   FPLP 18AWG 2C Specification

Download‍

Fire Alarm Line Shielded FPLR 12AWG 2C Specification

Download‍

Fire Alarm Line Shielded FPLR 12AWG 2C Specification

Download‍

Fire Alarm Line Shielded FPLR 14AWG 2C Specification

Download‍

Fire Alarm Cable Shielded FPLP 18AWG 4C Specification

Download‍
